| CNMG |
Insert Style: CNMG
|
431 |
ANSI Size Code: 431
|
| 120404 |
ISO Size Code: 120404
|
C - Diamond (Rhombic) 80-Deg |
Insert Shape: C - Diamond (Rhombic) 80-Deg
|
| 80.00 |
Included Angle: 80.00
|
0.5000 |
Inscribed Circle (Decimal Inch): 0.5000
|
| 1/2 |
Inscribed Circle (Inch): 1/2
|
12.70 |
Inscribed Circle (mm): 12.70
|
| 1/64 |
Corner Radius (Inch): 1/64
|
0.40 |
Corner Radius (mm): 0.40
|
| 0.0157 |
Corner Radius (Decimal Inch): 0.0157
|
Carbide |
Insert Material: Carbide
|
| AH8015 |
Manufacturer Grade: AH8015
|
TiAlN |
Coating/Finish: TiAlN
|
| 0.000 |
Relief Angle: 0.000
|
No |
Wiper Edge: No
|
| 3/16 |
Insert Thickness (Inch): 3/16
|
0.1875 |
Insert Thickness (Decimal Inch): 0.1875
|
| 4.76 |
Insert Thickness: 4.76
|
Neutral |
Insert Hand: Neutral
|
| CNMG-HRF |
Series: CNMG-HRF
|
Finishing |
Chip Breaker Operation: Finishing
|
| Cast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Stainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Steel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness |
Grade Characteristics: Cast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Stainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Steel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness
|
Negative |
Side Clearance: Negative
|
| 4 |
Number Of Cutting Edges: 4
|
C |
Insert Shape Code: C
|
| 0.2030 |
Hole Diameter (Decimal Inch): 0.2030
|
5.16 |
Hole Diameter (mm): 5.16
|
| 1.50 |
Maximum Depth of Cut (mm): 1.50
|
0.0590 |
Maximum Depth of Cut (Decimal Inch): 0.0590
|
| CNMG431 |
ANSI Insert Code: CNMG431
|
CNMG120404 |
ISO Insert Code: CNMG120404
|
| Pin; Clamp |
Insert Holding Method: Pin; Clamp
|
1/2 |
Width (Inch): 1/2
|
| N |
Clearance Code: N
|
M |
Tolerance Code: M
|
| PVD |
Coating Process: PVD
|
0.5000 - 0.6000 |
Length Range (Decimal Inch): 0.5000 - 0.6000
|
| Negative |
Rake: Negative
|
0.5080 |
Insert Length (Decimal Inch): 0.5080
|
| 12.90 |
Insert Length (mm): 12.90
|
Non-Ferrous Metal; Hard Material; Stainless Steel; Cast Iron; Superalloys & Titanium; Steel |
Primary Workpiece Material: Non-Ferrous Metal; Hard Material; Stainless Steel; Cast Iron; Superalloys & Titanium; Steel
|
| P; S; K; M |
Primary Workpiece Material Code: P; S; K; M
|
CNMG120404-HRF |
Iso Code: CNMG120404-HRF
|
| ISO; ANSI |
Standards: ISO; ANSI
|
6741632 |
Manufacturers Catalog Number: 6741632
|
| S20; S10; M20; M10 |
Material Grade: S20; S10; M20; M10
|
PVD |
Coating Classification: PVD
|
| HRF |
Chip Breaker: HRF
|
-20 |
Rake Angle: -20
|
| Honed |
Cutting Edge Style: Honed
|
CNMG 431 HRF |
Industry Standard Number: CNMG 431 HRF
|
| 0.5000 |
Width (Decimal Inch - 4 Decimals): 0.5000
|
Yes |
Multi-Use Tool: Yes
|
| No |
Full Radius: No
|
Facing; Turning; Boring |
Multi-Use Application: Facing; Turning; Boring
|
| 23242105 |
UNSPSC Code: 23242105
|
431 |
Insert Size Code: 431
|
| Japan |
Country of Origin: Japan
|
